Owner's manual

40
Technical data
Power supply unit (external)
Design voltage /-frequency 100 - 240 V AC 50/60 Hz
Power consumption max. 120 W
Calorimeter:
Design voltage 24 V DC 5A
Power consumption max. 120 W
Permissible duration of operation 100 %
Protection tzype acc. DIN EN 60529 IP 20
Protection class I
Overvoltage category 2
Contamination level II
Permissible ambient temperature 5 - 40 °C
Permissible relative humidity 80 %
Operation at a terrestrial altitude max. 2000 m
Dimensions (B x T x H) 290 x 300 x 280mm
Weiht 15 kg
Measuringrange(max.) 40.000J
Mode of the measuring isoperibol 22 °C
isoperibol 30 °C
Measuring time approx 7 min
Reproducibility (1g benzoic acid NBS39i) 0,15 %RSD
Working temperature 20 - 30 °C
Temperature measurement resolution 0,0001 K
Cooling medium temperature 19,5 K +/- 1,5 K for measuring mode isoperibol 22 °C
27,5 K +/- 1,5 K for measuring mode isoperibol 30 °C
Cooling medium permissible operating pressure 1,5 bar
Cooling medium tap water / drinking water quality
Cool art flow rate
Flow volume 50 ... 60 l/h
Oxygen operating pressure 30 ... 40bar
Interfaces RS232
USB-device
Subject to technical changes!
Maintenance
Warranty
The device is subject only to the natural wear and tear of compo-
nents and their statistical failure rate. According to the IKA ma-
nufacturer specifications we recommend an annual maintenance
with security check and pressure test according to Pressure Equip-
ment Directive!
Cleaning
For cleaning, disconnect the main plug!
Only use cleaning agents recommended by IKA
®
.
Contamination Cleaning agents
Dyes isopropyl alcohol
Building materials water containing tenside/isopropyl alcohol
Cosmetics water containing tenside/isopropyl alcohol
Foodstuffs water containing tenside
Fuels water containing tenside
-
When cleaning, please do not allow moisture to get into the unit.
- Wear the proper protective gloves during cleaning of the devices.
- Before performing a non-recommanded method of cleaning or
decontamination, the user must ascertain with IKA
®
that this me-
thod does not destroy the instrument.
Spare parts order
When ordering spare parts, please give:
- Machine type
- Serial number, see type plate
- Software Version (second displayed value when the device is on)
-
Item and designation of the spare part please see www.ika.com.
Repair
Please send instrument in for repair only after it has been
cleaned and is free from any materials which may consti-
tute a health hazard.
For this you should request the “Decontamination Clearance
Certificate” from IKA
®
, or use the download printout of it from
the IKA
®
website www.ika.com.
Return the instrument in its original packaging. Storage packaging
is not sucient. Also, please use suitable shipping package materi-
als.
In accordance with IKA
®
warranty conditions, the warranty period is 12 months. For claims under the warranty please contact your local
dealer. You may also send the machine directly to our factory, enclosing the delivery invoice and giving reasons for the claim. You will
be liable for freight costs.
The warranty does not cover worn out parts, nor does it apply to faults resulting from improper use, insufficient care or maintenance not
carried out in accordance with the instructions in this operating manual.
C1 092014
