11 DEFAULT
IRQ address 11
 Serial Port5 Address [2F0]
Selects the serial port base address.
Î
Disabled
No base address
Î
2F0 DEFAULT
I/O address 2F0
 Serial Port5 IRQ [10]
Use the Serial Port5 IRQ option to select the interrupt address for serial port 5.
Î
10 DEFAULT
IRQ address 10
5.3.4 Hardware Health Configuration
The Hardware Health Configuration menu (BIOS Menu 7) shows the operating
temperature, fan speeds and system voltages.
BIOS SETUP UTILITY
Main Advanced PCIPNP Boot Security Chipset Exit
Hardware Health Configuration
⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
CPU FAN Mode Setting [Full On mode]
⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
CPU Temperature :68ºC/154ºF
System Temperature :59ºC/138ºF
CPU Fan Speed :N/A
CPU Core :1.056 V
+1.05V :1.040 V
+3.30V :3.264 V
+5.00V :4.865 V
+12.0V :11.904 V
+1.50V :1.472 V
+1.80V :1.792 V
5VSB 4.919 V
VBAT 3.184 V
ÅÆ Select Screen
↑ ↓ Select Item
Enter Go to SubScreen
F1 General Help
F10 Save and Exit
ESC Exit
v02.61 ©Copyright 1985-2006, American Megatrends, Inc.
BIOS Menu 7: Hardware Health Configuration
