5.3.3 Super IO Configuration
Use the Super IO Configuration menu (BIOS Menu 6) to set or change the
configurations for the FDD controllers, parallel ports and serial ports.
BIOS SETUP UTILITY
Main Advanced PCIPNP Boot Security Chipset Exit
Configure Super I/O Chipset
⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
Serial Port1 Address [3F8/IRQ4]
Serial Port2 Address [2F8/IRQ3]
Allows BIOS to select
Serial Port Base
Addresses
ÅÆ Select Screen
↑ ↓ Select Item
Enter Go to SubScreen
F1 General Help
F10 Save and Exit
ESC Exit
V02.61 ©Copyright 1985-2006, American Megatrends, Inc.
BIOS Menu 6: Super IO Configuration
 Serial Port1 Address [3F8/IRQ4]
Selects the serial port base address.
Î
Disabled
No base address
Î
3F8/IRQ4 DEFAULT
I/O address 3F8 and interrupt address IRQ4
Î
3E8/IRQ4
I/O address 3E8 and interrupt address IRQ4
Î
2E8/IRQ3
I/O address 2E8 and interrupt address IRQ3
 Serial Port1 Mode [Normal]
Selects the mode for the serial port.
Î
Normal DEFAULT
Normal mode
Î
IrDA
IrDA mode
Î
ASK IR
ASKIR mode
