User guide

SAILORPC-12A Panel PC
Page 6
SPECIFICATION SAILORPC-12ASR SAILORPC-12A
Storage 1 x 2.5” SATA HDD bay
1 x CompactFlash® Type II slot
I/O 1 x 8-pin M12 connector for Gigabit LAN
1 x 5-pin M12 connector for CAN-bus and Audio line out
1 x 5-pin M12 connector for power input (9 V ~ 28 V)
1 x 8-pin M12 connector UART RS-232
1 x 8-pin M12 connector for RS-232/422/485
1 x 8-pin M12 connector for two USB
Power Requirement 9~28 VDC
Power Consumption 51 W 33 W
Touch Screen 5-wire resistive type with RS-232 interface
Cover Screw Torsion 7 kg-cm (6 lb-ft/0.68 Nm)
Front Panel Construction Aluminum
Chassis Construction Heavy-duty steel
Front Panel Color Silver (Pantone 8403C)
Front Panel Protection IP 67 compliant
Mounting Panel, rack, stand and arm (VESA 75 mm x 75 mm or
100 mm x 100 mm)
Operating Temperature -10ºC ~ 50ºC
Storage Temperature -20ºC ~ 70ºC
Vibration 5Hz~17Hz, 0.1" double amplitude displacement
17Hz~640Hz, 1.5G acceleration peak to peak
Shock 10G acceleration part to part (11ms)
Dimension (WxHxD) 345.3 mm x 300.4 mm x 77 mm
Weight (Net/Gross) 4.2 kg/5.3 kg
EMC and Safety CE, FCC, CB, CCC, DNV
Table 1-1: Technical Specifications
