PM-945GSE-N270 User Manual
Page 26
2 Dual USB cable (without bracket)
(P/N: 32000-070301-RS)
1 VGA cable
(P/N:32000-033804-RS)
1 Mini jumper pack
1 Quick Installation Guide
1 Utility CD
Table 2-1: Package List Contents
2.4 Optional Items
ATX power cable
(P/N: 32100-052100-RS)
SATA power cable
(P/N: 32100-068600-RS)
RS-422/485 Cable
(P/N: 32200-074800-RS)
5.1 channel AC'97 audio kit with Realtek ALC655 codec
(P/N: AC-KIT08R-R10)
7.1 channel HD audio kit with Realtek ALC883 codec
(P/N: AC-KIT883HD-R10)
Table 2-2: Package List Contents (Optional Items)
