LCD-KIT
Page 66
Figure C-6: smartOSD Installation Complete
Step 12: Click Close in the screen above.
Step 13: After quick setup is complete, the IEI smartOSD wizard logo appears on the
desktop as shown in the screen below.
Step 14: To access the smartOSD, click the smartOSD wizard logo.Step 0:
Figure C-7: smartOSD Desktop Icon
