This item allows fine-tuning the balance among Red, Green, and Blue
color hues if images look garish or unrealistic.
6.2.4 Image Settings
The image settings are shown in Figure 6-6.
Figure 6-6: Image Settings Menu
Image settings are described below.

Auto Color:
Automatically adjusts the color settings.

Width:
Adjusts the width of the display screen.

Phase:
Adjusts the input signal and dot clock position (Analog only).

H. Position:
Adjusts the horizontal position of the display screen.
