LCD-KIT
Page 51
Mute:
This item mutes the audio. It is only implemented with models equipped
with speakers.
Gamma:
This item allows user to calibrate the monitor by hardware.
6.2.3 Color
Color options are shown in Figure 6-5.
Figure 6-5: Color Options
The Color menu fine-tunes the palette of color hues for the LCD.
9300k:
NTSC standard Kelvin
7500k:
NTSC standard Kelvin
6500k:
NTSC standard Kelvin
User Temp:
