Level 0 Level 1 Value
H. Position 0 to 100
V. Position 0 to 100
OSD Time Out 0 to 60 sec
OSD Position 1 to 5
OSD Menu
Factory Reset Select
Digital Signal Menu
Analog
Select
Table 6-1: OSD Menus
6.2 Using the OSD
OSD menu options are described below.
6.2.1 Main Display Features
Main display features are shown in Figure 6-3.
Figure 6-3: Main Display Features
Brightness:
