LVDS connector 30-pin connector CN5
Power output connector (+12 V) 2-pin wafer connector CN3
Power output connector (+5 V) 2-pin wafer connector CN4
Power input connector 3-pin connector CN2
RS-232 and USB signal input connector 12-pin wafer
connector
CN14
Touchscreen connector 9-pin wafer connector J4
VGA connector 10-pin box header VGA2
Table 4-5: AV-6600 Peripheral Interface Connectors
4.4.2 AV-6600 Rear Panel Connectors
Table 4-6 lists the rear panel connectors on the AV-6600 AD board.
Connector Type Label
Audio input jack Audio jack J3
12V DC power connector DC Power Jack CN13
DVI connector 24-pin DVI-D connector J2
VGA connector 15-pin VGA connector VGA1
Table 4-6: AV-6600 Rear Panel Connectors
