3.2 Power Adapters
Table 3-9 lists the AC/DC power adapter specifications.
LCD-KIT 190G, 170G, 150G, 121G/XG 104GH, 84GH, 65GH
Power 50 Watt AC/DC Adapter 35 Watt AC/DC Adapter
General Description Universal Input 90 to 264 VAC
EMI Meets FCC/CISPR 22 Class B
MTBF 165Khrs
Limited Power Source
Universal Input 90 to 264 VAC
EMI Meets FCC/CISPR 22 Class B
MTBF 300Khrs
Limited Power Source
Input Voltage Range 90-264VAC 90-264VAC
Input Frequency 47-63 Hz 47-63 Hz
Inrush Current 40A max. (Cold Start) 30A max. (Cold Start)
Hold-up Time 10mS typical 10mS typical
Leakage Current 0.5mA max. 3.5mA max.
Short Circuit Protection Continuous Continuous
Over-voltage Protection Yes Yes
Continuous Output Power 50W max. 35W max.
Hi-pot Isolation:
Input / Output
4242VDC 4242VDC
Table 3-9: Power Adapter Specifications
