LCD-KIT
Page 31
3.1.9 LCD-KIT65GH LCD Specifications
The table below lists the LCD-KIT65GH LCD specifications.
Model
LCD-KIT65GH
Size
6.5”
MFR/Model
AUO/G065VN01 V2
Resolution
VGA (640 x 480)
Active Area (mm)
132.48 x 99.36
Pixel Pitch (mm)
0.207
Mode
TN
Number of Colors
262K
Color Saturation (NTSC%)
55
View Angle (H/V)
160/140
Brightness (cd/m2)
800
Contrast Ratio
600:1
Response Time (ms) (at 25C)
25
Power Consumption (W)
3.86
Interface
LVDS
Supply Voltage (V)
3.3
Backlight
LED
Table 3-8: LCD-KIT65GH LCD Specifications
