3.1.8 LCD-KIT84GH LCD Specifications
The table below lists the LCD-KIT84GH LCD specifications.
Model
LCD-KIT84GH
Size
8.4”
MFR/Model
AUO/G084SN05 V8
Resolution
SVGA (800 x 600)
Active Area (mm)
170.4 x 127.8
Pixel Pitch (mm)
0.213
Mode
TN
Number of Colors
262K
View Angle (H/V)
160 / 140
Brightness (cd/m2)
450
Contrast Ratio
600:1
Response Time (ms) (at 25C)
30
Power Consumption (W)
4.2
Interface
LVDS
Supply Voltage (V)
3.3
Backlight
LED
Color Saturation (NTSC%)
45
Table 3-7: LCD-KIT84GH LCD Specifications
