3.1.7 LCD-KIT104GH LCD Specifications
The table below lists the LCD-KIT104GH LCD specifications.
Model
LCD-KIT104GH
Size
10.4”
MFR/Model
AUO/G104SN02 V2
Resolution
SVGA (800 x 600)
Active Area (mm)
211.2 x 158.4
Pixel Pitch (mm)
0.264
Mode
TN
Number of Colors
262K
View Angle (H/V)
160 / 140
Brightness (cd/m2)
400
Contrast Ratio
700:1
Response Time (ms) (at 25C)
30
Power Consumption (W)
5.2
Interface
1ch LVDS
Supply Voltage (V)
3.3
Backlight
LED
Color Saturation (NTSC%)
45
Table 3-6: LCD-KIT104GH LCD Specifications
