3.1.6 LCD-KIT121G LCD Specifications
The table below lists the LCD-KIT121G LCD specifications.
Model
LCD-KIT121G
Size
12.1”
MFR/Model
AUO/G121SN01 V4
Resolution
SVGA (800 x 600)
Active Area (mm)
245.76 x 184.32
Pixel Pitch (mm)
0.3075
Mode
TN
Number of Colors
262K
View Angle (H/V)
160/140
Brightness (cd/m2)
450
Contrast Ratio
700:1
Response Time (ms) (at 25C)
35
Power Consumption (W)
6.7
Interface
1ch LVDS
Supply Voltage (V)
3.3
Backlight
LED
Color Saturation (NTSC%)
55
Table 3-5: LCD-KIT121G LCD Specifications
