LCD-KIT
Page 27
3.1.5 LCD-KIT121GX LCD Specifications
The table below lists the LCD-KIT121GX LCD specifications.
Model
LCD-KIT121GX
Size
12.1”
MFR/Model
AUO/G121XN01 V0
Resolution
SVGA (1024 x 768)
Active Area (mm)
245.76 x 184.32
Pixel Pitch (mm)
0.3075
Mode
TN
Number of Colors
262K
View Angle (H/V)
160/160
Brightness (cd/m2)
500
Contrast Ratio
700:1
Response Time (ms) (at 25C)
35
Power Consumption (W)
9.15
Interface
1ch LVDS
Supply Voltage (V)
3.3
Backlight
LED
Color Saturation (NTSC%)
70
Table 3-4: LCD-KIT121GX LCD Specifications
