3.1.4 LCD-KIT150G LCD Specifications
The table below lists the LCD-KIT150G LCD specifications.
Model
LCD-KIT150
G
Size
15”
MFR/Model
AUO/G150XG
01 V1
Resolution
XGA (1024 x
768)
Active Area (mm)
304.1 x 228.1
Pixel Pitch (mm)
0.297
Mode
TN
Number of Colors
16.2M
Color Saturation (NTSC%)
65
View Angle (H/V)
140/120
Brightness (cd/m2)
350
Contrast Ratio
700:1
Response Time (ms) (at 25C)
8
Power Consumption (W)
8.9
Interface
1ch LVDS
Supply Voltage (V)
3.3
Backlight
2 CCFL
Lamp Life (hrs)
50000
Table 3-3: LCD-KIT150G LCD Specifications
