LCD-KIT
Page 24
3.1.2 LCD-KIT190G LCD Specifications
The table below lists the LCD-KIT190G LCD specifications.
Model
LCD-KIT190G
Size
19”
MFR/Model
HANNSTAR/HSD190M
EN3-A
Resolution
SXGA (1280 x 1024)
Active Area (mm)
376.32 x 301.06
Pixel Pitch (mm)
0.294
Mode
TN
Number of Colors
16.7M
Color Saturation (NTSC%)
72
View Angle (H/V)
170 / 160
Brightness (cd/m2)
300
Contrast Ratio
1000:1
Response Time (ms) (at 25C)
5
Interface
2ch LVDS
Supply Voltage (V)
5
Backlight
4 CCFL
Table 3-1: LCD-KIT190G LCD Specifications
