 9~36 V DC power connector
2.3.5 Variant 4 Connectors
The following is a list of the bottom panel peripheral device connectors used on the
LCD-KIT121GXM, LCD-KIT150GM, LCD-KIT170GM and LCD-KIT190GM series monitor.
 VGA connector
 DVI-D connector
 9~36 V DC power connector
2.4 Physical Dimensions
The following sections describe the physical dimensions for each model of the LCD-KIT
series monitor.
2.4.1 General Physical Dimensions
General physical dimensions for the LCD-KIT series monitors are shown in Table 2-2.
Model Width (mm) Height (mm) Depth (mm)
LCD-KIT190G 427.9 327.4 48.4
LCD-KIT170GS 390.4 300 46.9
LCD-KIT150G 364.1 262.5 41.9
LCD-KIT121G/GX 294 240.7 42
LCD-KIT104GH 242.2 209 33.6
LCD-KIT84GH 234 147 35.3
LCD-KIT65GH 203 121 34
Table 2-2: General Physical Dimensions
