LCD-KIT Chapter 1 1 Introduction Page 1
LCD-KIT 1.1 LCD-KIT Series Monitor Overview The LCD-KIT series monitor is the latest member of IEI’s line of sophisticated LCD designs, and it has been improved to be RoHS compliant. It is designed to fit industrial automation, or any other applications that require minimum installation space and flexible configuration. Flexible analog or digital interfaces are provided for ease of connection with a management computer.
LCD-KIT LCD-KIT190GM: 19” TFT LCD, 9~36 V DC power input 1.2 Applications and Features 1.2.1 LCD-KIT Series Monitor Applications IEI’s series of LCD kits are designed for system manufacturers, integrators, or value-added resellers that want to provide all the performance, quality and reliability of an LCD display solution at a cost effective price. IEI’s LCD kits offer additional components such as cables, an inverter and power supply with controller interfaces that include VGA and DVI. 1.2.
LCD-KIT Figure 1-1: Typical LCD-KIT Front View 1.3.2 Rear View The rear of the LCD-KIT series monitor is a metal chassis. An on screen display (OSD) control button panel, if present, is located vertically on the left side of the chassis with the following control buttons: LCD On/Off Auto Left Right Menu The OSD panel also has one power LED. Figure 1-2 shows a typical LCD-KIT rear panel.
LCD-KIT Figure 1-2: Typical LCD-KIT Rear View 1.3.3 Connectors Each LCD-KIT series monitor has a number of interface connectors on either the top or right panel of the chassis (when viewing the rear panel). Figure 1-3 shows a typical LCD-KIT connector panel. Each model may include or exclude additional connectors. Refer to Section 2.3 for listings of LCD-KITs and their connectors. All connectors are fully described in Section 5.4.
LCD-KIT 1.3.4 AD Board The LCD-KIT series monitor AD boards provide a wide variety of control interfaces, receiving and managing signals from a CPU card through cabling. Figure 1-4 shows the AV-6600 AD board as a sample of a typical AD board for the LCD-KIT series monitor. Refer to Chapter 4 for a complete description of AD boards and their connectors.
LCD-KIT 1.4 Series Specifications The table below shows the LCD-KIT Series specifications. LCD-KIT LCD Type 65GH 84GH 6.5" TFT 8.4" TFT Input Interface Max. 104GH 121G 121GX 10.4" TFT 12.1" TFT 12.1” TFT VGA 150G 170G 15" TFT 190G 17" TFT 19" TFT VGA + DVI-D 640x480 800x600 1024x768 1280x1024 Resolution Backlight MTBF 50,000 Hrs Contrast 600:1 700:1 LCD Color Brightness 800:1 262K 1000:1 16.
LCD-KIT LCD-KIT 65GH 84GH 104GH 121G 121GX 150G 170G Dimension 203 x 234 x 242.2 x 294 x 294 x 364.1 x 390.4 x 427.9 x (WxHxD) (mm) 121 x 147 x 209 x 240.7 x 240.7 x 262.5 x 300 x 327.4 x 34 35.3 33.6 42 42 41.9 46.9 48.4 -20°C ~ 50°C Operation Temperature Table 1-1: LCD-KIT Series Specifications 1.
LCD-KIT Chapter 2 2 Mechanical Overview Page 9
LCD-KIT 2.1 Introduction This chapter describes the general mechanical overview of the LCD-KIT series monitors including rear panel variations, available interfaces and overall dimensions. 2.2 Rear Panel The rear panel of the LCD-KIT series monitor is comprised of a metal chassis with an OSD control panel. 2.2.1 Rear Panel Variants Table 2-1 shows the rear panel variants for the LCD-KIT series monitor.
LCD-KIT LCD-KIT104GH LCD-KIT84GH Figure 2-1 shows the location of the rear panel variant 1 OSD controls. Figure 2-1: Rear Panel Variant 1 2.2.3 Rear Panel Variant 2 The following model of the LCD-KIT series monitor has OSD control buttons located on the bottom of the rear panel: LCD-KIT65GH Figure 2-2 shows the location of the rear panel variant 2 OSD controls.
LCD-KIT 2.3 Connector Panel All external peripheral interface connectors are located on the rear panel of the LCD-KIT series monitor. The following sections describe the rear panel variants and their associated connectors. 2.3.1 Available Connectors There are a number of rear panel peripheral device connectors available for the LCD-KIT series monitor. VGA connector DVI-D connector 12 V DC power connector 9~36 V DC power connector 2.3.
LCD-KIT 9~36 V DC power connector 2.3.5 Variant 4 Connectors The following is a list of the bottom panel peripheral device connectors used on the LCD-KIT121GXM, LCD-KIT150GM, LCD-KIT170GM and LCD-KIT190GM series monitor. VGA connector DVI-D connector 9~36 V DC power connector 2.4 Physical Dimensions The following sections describe the physical dimensions for each model of the LCD-KIT series monitor. 2.4.
LCD-KIT 2.4.2 LCD-KIT190G Physical Dimensions The physical dimensions of the LCD-KIT190G are shown in Figure 2-3.
LCD-KIT 2.4.3 LCD-KIT170GS Physical Dimensions The physical dimensions of the LCD-KIT170GS are shown in Figure 2-4.
LCD-KIT 2.4.4 LCD-KIT150G Physical Dimensions The physical dimensions of the LCD-KIT150G are shown in Figure 2-5.
LCD-KIT 2.4.5 LCD-KIT121G/GX Physical Dimensions The physical dimensions of the LCD-KIT121G/GX are shown in Figure 2-6.
LCD-KIT 2.4.6 LCD-KIT104GH Physical Dimensions The physical dimensions of the LCD-KIT104GH are shown in Figure 2-7.
LCD-KIT 2.4.7 LCD-KIT84GH Physical Dimensions The physical dimensions of the LCD-KIT84GH are shown in Figure 2-8.
LCD-KIT 2.4.8 LCD-KIT65GH Physical Dimensions The physical dimensions of the LCD-KIT65GH are shown in Figure 2-9.
LCD-KIT 2.5 Mounting Options Each LCD-KIT series monitor has mounting holes located on the mounting bracket. Table 2-3 details the number of mounting holes for each model of the LCD-KIT series monitor. Refer to Section 2.4 for more information. Model No. of Round Holes - Size No. of Slotted Holes LCD-KIT190G 6 – 4 mm diameter 8 LCD-KIT170G 6 – 4.5 mm diameter 8 LCD-KIT150G 6 – 4.5 mm diameter 8 LCD-KIT121G/GX 4 – 3.5 mm diameter - LCD-KIT104GH 4 – 3.5 mm diameter - LCD-KIT84GH 4 – 3.
LCD-KIT Chapter 3 3 LCD Specifications Page 22
LCD-KIT 3.1 LCD Specifications 3.1.1 LCD Overview The LCD-KIT series industrial monitors use the following LCD panels. LCD-KIT190G: HANNSTAR/HSD190MEN3-A LCD-KIT170G: AUO G170EG01 V0 LCD-KIT150G: AUO G150XG01 V1 LCD-KIT121GX: LCD-KIT121G: LCD-KIT104GH: AUO/G104SN02 V2 LCD-KIT084GH: AUO/G084SN05 V8 LCD-KIT65GH: AUO G121XN01 V0 AUO G121SN01 V4 AUO/G065VN01 V2 Detailed specifications for the LCD screens are listed in the following sections.
LCD-KIT 3.1.2 LCD-KIT190G LCD Specifications The table below lists the LCD-KIT190G LCD specifications. Model LCD-KIT190G Size 19” MFR/Model HANNSTAR/HSD190M EN3-A Resolution SXGA (1280 x 1024) Active Area (mm) 376.32 x 301.06 Pixel Pitch (mm) 0.294 Mode TN Number of Colors 16.
LCD-KIT 3.1.3 LCD-KIT170G LCD Specifications The table below lists the LCD-KIT170G LCD specifications. Model LCD-KIT170G Size 17” MFR/Model AUO/G170EG01 V0 Resolution SXGA (1280 x 1024) Active Area (mm) 337.9 x 270.3 Pixel Pitch (mm) 0.264 Mode TN Number of Colors 16.7M Color Saturation (NTSC%) 72 View Angle (H/V) 170/160 Brightness (cd/m2) 350 Contrast Ratio 800:1 Response Time (ms) (at 25C) 8 Power Consumption (W) 25.
LCD-KIT 3.1.4 LCD-KIT150G LCD Specifications The table below lists the LCD-KIT150G LCD specifications. Model LCD-KIT150 G Size 15” MFR/Model AUO/G150XG 01 V1 Resolution XGA (1024 x 768) Active Area (mm) 304.1 x 228.1 Pixel Pitch (mm) 0.297 Mode TN Number of Colors 16.2M Color Saturation (NTSC%) 65 View Angle (H/V) 140/120 Brightness (cd/m2) 350 Contrast Ratio 700:1 Response Time (ms) (at 25C) 8 Power Consumption (W) 8.9 Interface 1ch LVDS Supply Voltage (V) 3.
LCD-KIT 3.1.5 LCD-KIT121GX LCD Specifications The table below lists the LCD-KIT121GX LCD specifications. Model LCD-KIT121GX Size 12.1” MFR/Model AUO/G121XN01 V0 Resolution SVGA (1024 x 768) Active Area (mm) 245.76 x 184.32 Pixel Pitch (mm) 0.3075 Mode TN Number of Colors 262K View Angle (H/V) 160/160 Brightness (cd/m2) 500 Contrast Ratio 700:1 Response Time (ms) (at 25C) 35 Power Consumption (W) 9.15 Interface 1ch LVDS Supply Voltage (V) 3.
LCD-KIT 3.1.6 LCD-KIT121G LCD Specifications The table below lists the LCD-KIT121G LCD specifications. Model LCD-KIT121G Size 12.1” MFR/Model AUO/G121SN01 V4 Resolution SVGA (800 x 600) Active Area (mm) 245.76 x 184.32 Pixel Pitch (mm) 0.3075 Mode TN Number of Colors 262K View Angle (H/V) 160/140 Brightness (cd/m2) 450 Contrast Ratio 700:1 Response Time (ms) (at 25C) 35 Power Consumption (W) 6.7 Interface 1ch LVDS Supply Voltage (V) 3.
LCD-KIT 3.1.7 LCD-KIT104GH LCD Specifications The table below lists the LCD-KIT104GH LCD specifications. Model LCD-KIT104GH Size 10.4” MFR/Model AUO/G104SN02 V2 Resolution SVGA (800 x 600) Active Area (mm) 211.2 x 158.4 Pixel Pitch (mm) 0.264 Mode TN Number of Colors 262K View Angle (H/V) 160 / 140 Brightness (cd/m2) 400 Contrast Ratio 700:1 Response Time (ms) (at 25C) 30 Power Consumption (W) 5.2 Interface 1ch LVDS Supply Voltage (V) 3.
LCD-KIT 3.1.8 LCD-KIT84GH LCD Specifications The table below lists the LCD-KIT84GH LCD specifications. Model LCD-KIT84GH Size 8.4” MFR/Model AUO/G084SN05 V8 Resolution SVGA (800 x 600) Active Area (mm) 170.4 x 127.8 Pixel Pitch (mm) 0.213 Mode TN Number of Colors 262K View Angle (H/V) 160 / 140 Brightness (cd/m2) 450 Contrast Ratio 600:1 Response Time (ms) (at 25C) 30 Power Consumption (W) 4.2 Interface LVDS Supply Voltage (V) 3.
LCD-KIT 3.1.9 LCD-KIT65GH LCD Specifications The table below lists the LCD-KIT65GH LCD specifications. Model LCD-KIT65GH Size 6.5” MFR/Model AUO/G065VN01 V2 Resolution VGA (640 x 480) Active Area (mm) 132.48 x 99.36 Pixel Pitch (mm) 0.207 Mode TN Number of Colors 262K Color Saturation (NTSC%) 55 View Angle (H/V) 160/140 Brightness (cd/m2) 800 Contrast Ratio 600:1 Response Time (ms) (at 25C) 25 Power Consumption (W) 3.86 Interface LVDS Supply Voltage (V) 3.
LCD-KIT 3.2 Power Adapters Table 3-9 lists the AC/DC power adapter specifications.
LCD-KIT Chapter 4 4 AD Boards Page 33
LCD-KIT 4.1 AD Board Overview The LCD-KIT series industrial monitor AD board provides a wide variety of control interfaces, receiving and managing interface signals from a CPU card through cabling. There are three AD boards used for the LCD-KIT series monitors: AV-9650, AV-6650 and AV-6600. Refer to Section 1.4 for a listing of LCD-KIT series monitors and their associated AD board. The following sections describe each AD board in detail. 4.
LCD-KIT 4.2.1 AV-9650 Peripheral Interface Connectors Table 4-1 shows a list of the peripheral interface connectors on the AV-9650 AD board.
LCD-KIT 4.
LCD-KIT 4.3.1 AV-6650 Peripheral Interface Connectors Table 4-3 shows a list of the peripheral interface connectors on the AV-6650 AD board.
LCD-KIT Figure 4-3: AV-6600 AD Board Overview 4.4.1 AV-6600 Peripheral Interface Connectors Table 4-5 shows a list of the peripheral interface connectors on the AV-6600 AD board.
LCD-KIT LVDS connector 30-pin connector CN5 Power output connector (+12 V) 2-pin wafer connector CN3 Power output connector (+5 V) 2-pin wafer connector CN4 Power input connector 3-pin connector CN2 RS-232 and USB signal input connector 12-pin wafer connector CN14 Touchscreen connector 9-pin wafer connector J4 VGA connector 10-pin box header VGA2 Table 4-5: AV-6600 Peripheral Interface Connectors 4.4.
LCD-KIT Chapter 5 5 Installation Page 40
LCD-KIT 5.1 Installation Precautions When installing the LCD-KIT series monitor, please follow the precautions listed below: Read the user manual: The user manual provides a complete description of the LCD-KIT series monitor, installation instructions and configuration options. DANGER! Disconnect Power: Power to the monitor must be disconnected when installing the LCD-KIT series monitor, or before any attempt is made to access the rear panel.
LCD-KIT 5.2 Unpacking 5.2.1 Packaging When shipped, the LCD-KIT series monitor is wrapped in a plastic bag. Two polystyrene ends are placed on either side of the monitor. The monitor is then placed into a first (internal) cardboard box. This box is then sealed and placed into a second (external) cardboard box. The second box is also sealed. A bag containing accessory items is placed with the monitor in the internal (first) box. 5.2.
LCD-KIT 5.2.3 Packing List All the monitors in the LCD-KIT series are shipped with the following components: 1 x LCD-KIT series monitor.
LCD-KIT 5.4 Connectors Table 5-1 lists the rear panel connectors for the LCD-KIT series monitors. LCD-KIT 65GH DVI-D - VGA Yes Power (12V Jack) Yes 84GH 104GH 121G/GX 150G 170G 190G Yes Table 5-1: Rear Panel Connectors 5.4.1 VGA Connector Use the rear panel standard 15-pin female VGA connector to connect the monitor to the system graphics interface.
LCD-KIT Pin Description Pin Description Pin Description 1 TMDS Data2- 9 TMDS Data1- 17 TMDS Data0- 2 TMDS Data2+ 10 TMDS Data1+ 18 TMDSData0+ 3 TMDS Data2/4 Shield 11 TMDS Data1/3 Shield 19 TMDS Data0/5 Shield 4 TMDS Data4- 12 TMDS Data3- 20 TMDS Data5- 5 TMDS Data4+ 13 TMDS Data3+ 21 TMDS Data5+ 6 DDC Clock [SCL] 14 +5 V Power 22 TMDS Clock Shield 7 DDC Data [SDA] 15 Ground (for +5 V) 23 TMDS Clock + 8 Analog vertical sync 16 Hot Plug Detect 24 TMDS Cloc
LCD-KIT Chapter 6 6 OSD Controls Page 46
LCD-KIT 6.1 User Mode OSD Structure 6.1.1 OSD Buttons There are several on-screen-display (OSD) control buttons oriented either vertically along the right hand side or horizontally along the bottom of the monitor front panel. Refer to Section 2.2 for availability and orientation of the OSD controls on specific LCD-KIT series monitors. Figure 6-1 shows a typical arrangement of OSD controls for all models except the 6.5" model. Figure 6-1: OSD Control Buttons (Except 6.
LCD-KIT Figure 6-2: LCD-KIT65 OSD Control Buttons 6.1.2 OSD Menu Structure Table 6-1 shows the OSD menu structure for all models of the LCD-KIT series LCD monitor. Level 0 Level 1 Value Main Display Features Menu Brightness 0 to 100 Contrast 0 to 100 Horizontal Size 0 to 100 Sharpness 1 to 5 Volume This menu is currently disabled, and Mute will be implemented with models Speaker Menu equipped with speakers.
LCD-KIT Level 0 OSD Menu Signal Menu Level 1 Value H. Position 0 to 100 V. Position 0 to 100 OSD Time Out 0 to 60 sec OSD Position 1 to 5 Factory Reset Select Digital Select Analog Table 6-1: OSD Menus 6.2 Using the OSD OSD menu options are described below. 6.2.1 Main Display Features Main display features are shown in Figure 6-3.
LCD-KIT The brightness option adjusts the brightness of screen. This function adjusts the offset value of ADC. Setting this value too high or too low will affect the quality of image. Contrast: This function adjusts the gain value of ADC. Adjusting this value too high or too low will worsen the quality of image. Horizontal Size: This item adjusts the screen size in the horizontal direction. 6.2.2 Gamma Gamma options are shown in Figure 6-5.
LCD-KIT Mute: This item mutes the audio. It is only implemented with models equipped with speakers. Gamma: This item allows user to calibrate the monitor by hardware. 6.2.3 Color Color options are shown in Figure 6-5. Figure 6-5: Color Options The Color menu fine-tunes the palette of color hues for the LCD.
LCD-KIT This item allows fine-tuning the balance among Red, Green, and Blue color hues if images look garish or unrealistic. 6.2.4 Image Settings The image settings are shown in Figure 6-6. Figure 6-6: Image Settings Menu Image settings are described below. Auto Color: Automatically adjusts the color settings. Width: Adjusts the width of the display screen. Phase: Adjusts the input signal and dot clock position (Analog only). H.
LCD-KIT V. Position: Adjusts the vertical position of the display screen. 6.2.5 OSD Configurations The OSD configurations are shown in Figure 6-7. Figure 6-7: OSD Configurations Menu OSD Configurations are described below. OSD Time Out: Determines how many seconds the OSD screen stays on screen before it disappears when OSD is left unattended. OSD Position: Adjusts the OSD position on the screen.
LCD-KIT 6.2.
LCD-KIT Appendix A A Certifications Page 55
LCD-KIT A.1 RoHS Compliant All models in the LCD-KIT series comply with the Restriction of Hazardous Materials (RoHS) Directive. This means that all components used to build the industrial workstations and the workstation itself are RoHS compliant.
LCD-KIT Appendix B B Safety Precautions Page 57
LCD-KIT WARNING: The precautions outlined in this chapter should be strictly followed. Failure to follow these precautions may result in permanent damage to the LCD-KIT Series. B.1 Safety Precautions Please follow the safety precautions outlined in the sections that follow: B.1.1 General Safety Precautions Please ensure the following safety precautions are adhered to at all times. Follow the electrostatic precautions outlined below whenever the LCD-KIT Series is opened.
LCD-KIT B.1.2 Anti-static Precautions WARNING: Failure to take ESD precautions during the installation of the LCD-KIT Series may result in permanent damage to the LCD-KIT Series and severe injury to the user. Electrostatic discharge (ESD) can cause serious damage to electronic components, including the LCD-KIT Series. Dry climates are especially susceptible to ESD.
LCD-KIT Except for the LCD panel, never spray or squirt liquids directly onto any other components. To clean the LCD panel, gently wipe it with a piece of soft dry cloth or a slightly moistened cloth. The interior of the LCD-KIT Series does not require cleaning. Keep fluids away from the LCD-KIT Series interior. Be cautious of all small removable components when vacuuming the LCD-KIT Series. Turn the LCD-KIT Series off before cleaning the LCD-KIT Series.
LCD-KIT Appendix C C smartOSD Page 61
LCD-KIT C.1 IEI smartOSD Quick Installation Guide IEI smartOSD is a proprietary On-Screen-Display (OSD) software solution from IEI that enables easy, remote monitor setting adjustments in a Windows environment. IEI smartOSD delivers excellent performance and provides more flexibility than the typical OSD hardware solutions when adjusting a monitor.
LCD-KIT C.3 smartOSD Install Connect the LCD-KIT to a host computer. Insert the CD that came with the system and follow the instructions below. Step 1: When the CD installs the screen shown in Figure C-1 appears. Figure C-1: smartOSD Installer Step 2: Click “Smart OSD” in Figure C-1. Step 3: The welcome screen shown in Figure C-2 appears.
LCD-KIT Figure C-2: smartOSD Welcome Screen Step 4: Click Next to continue. Step 5: The Folder Select screen in Figure C-3 appears. Figure C-3: smartOSD Folder Select Screen Step 6: Select the installation folder in Figure C-3 shown above. Step 7: Click Next to continue. Step 8: The screen in Figure C-4 appears.
LCD-KIT Figure C-4: smartOSD Confirm Installation Step 9: Confirm the installation by clicking Next in the screen above. Step 10: The program starts to install and the progress bar shown in Figure C-5 appears. Figure C-5: smartOSD Installation Progress Step 11: When the installation is complete the “Complete Installation” screen in Figure C-6 appears.
LCD-KIT Figure C-6: smartOSD Installation Complete Step 12: Click Close in the screen above. Step 13: After quick setup is complete, the IEI smartOSD wizard logo appears on the desktop as shown in the screen below. Step 14: To access the smartOSD, click the smartOSD wizard logo.
LCD-KIT C.4 Software Illustration The table below shows the smartOSD menu structure for all IEI LCD monitors. NOTE: To update the display setting status immediately, push the refresh button on every page To turn the system on, press ALT + P. Item Elements Management Save/Load File Power Management EDID EDID contains basic information about the monitor and its capabilities.
LCD-KIT Item Elements PIP Source Input (disabled in the LCD-KIT Series) PIP Size (disabled in the LCD-KIT Series) System Monitor Power Control Auto Brightness (disabled in the LCD-KIT Series) Main Source Input (S-Video and CVBS disabled) Volume (disabled in the LCD-KIT Series) Factory Presets/OSD Lock/OSD Unlock Mute (disabled in the LCD-KIT Series) Table C-1: SmartOSD Menu Structure Page 68
LCD-KIT C.4.
LCD-KIT C.4.
LCD-KIT C.4.
LCD-KIT C.4.
LCD-KIT C.4.
LCD-KIT C.4.6 PIP Page NOTE: The functions in the PIP page are only available in the MLCD-KIT Series and AFOLUX Series monitors.
LCD-KIT C.4.
LCD-KIT NOTE: Some of the functions in the System Page are only available to some of the IEI LCD series as following: Auto Brightness: SRM, MLCD-KIT and AFOLUX series only Page 76 Main Source Input: MLCD-KIT and AFOLUX series only Volume: AFOLUX series only Mute: AFOLUX series only
LCD-KIT C.4.
LCD-KIT C.5 smartOSD FAQ For troubleshooting, please see the steps below: C.5.1 Windows 2000 Installation Failure Installation fails under Windows 2000 and shows the following image: Figure C-16: DLL Missing Solution: Download and install service pack Windows Installer 3.
LCD-KIT C.5.2 Vista Installation Failure Installation fails under Vista while showing following image: Figure C-17: Windows Vista Error Solution: Install SmartOSD.
LCD-KIT C.5.3 Model Failure The Model Fail error message shown below appears. Figure C-19: Firmware Incompatibility Solution: SmartOSD only supports firmware version 2.0 and following versions. C.5.4 DCC Port Failure The DDC port fail error message shown below appears. Figure C-20: DCC Port Failure Solutions: Check VGA or DVI cable Check an IEI monitor is being used Make sure the version is version 2.3 for the AFOLUX/MLCD-KIT series and version 1.
