KINO-G410 Mini-ITX Motherboard
Page 82
5.3.7 USB Configuration
Use the USB Configuration menu (BIOS Menu 12) to read USB configuration
information and configure the USB settings.
BIOS SETUP UTILITY
Main
Advanced
PCIPnP
Boot
Security
Chipset
Exit
USB Configuration
Module Version – 2.24.3-13.4
USB Devices Enabled:
1 Keyboard
USB Functions [Enabled]
USB 2.0 Controller [Enabled]
Legacy USB Support [Enabled]
USB 2.0 Controller Mode [HiSpeed]
Options
Disabled
Enabled
Select Screen
↑ ↓ Select Item
+ - Change Option
F1 General Help
F10 Save and Exit
ESC Exit
v02.61 ©Copyright 1985-2006, American Megatrends, Inc.
BIOS Menu 12: USB Configuration
USB Functions [Enabled]
Use the USB Functions option to enable or disable the USB controllers.
Disabled
USB controllers are enabled
Enabled DEFAULT
USB controllers are disabled
USB 2.0 Controller [Enabled]
The USB 2.0 Controller BIOS option enables or disables the USB 2.0 controller
Disabled
USB function disabled
Enabled DEFAULT
USB function enabled
Legacy USB Support [Enabled]
Use the Legacy USB Support BIOS option to enable USB mouse and USB keyboard
support.
