Manual

KINO-G410 Mini-ITX Motherboard
Page 81
Use the Serial Port Mode option to select baud rate through which the console redirection
is made. The following configuration options are available
 115200 8,n,1 D
EFAULT
 57600 8,n,1
 38400 8,n,1
 19200 8,n,1
 09600 8,n,1
NOTE:
Identical baud rate setting must be set on
the host (a management computer
running a terminal software) and the slave
 Redirection After BIOS POST [Alwa ys ]
Use the Redirection After BIOS POST option to specify when console redirection should
occur.

Disabled
The console is not redirected after POST

Boot Loader
Redirection is active during POST and during Boot
Loader

Always D
EFAULT
Redirection is always active (Some OSes may not
work if set to Always)
 Terminal Type [ANSI]
Use the Terminal Type BIOS option to specify the remote terminal type.

ANSI D
EFAULT
The target terminal type is ANSI

VT100
The target terminal type is VT100

VT-UTF8
The target terminal type is VT-UTF8
