KINO-G410 Mini-ITX Motherboard
Page 75
Manual Mode
by RPM
The fan spins at the speed set in Manual Mode by
RPM settings
Manual Mode
by Duty-Cycle
The fan spins at the speed set in Manual Mode by
Duty-Cycle settings
S YS Te m p . Limit of Highes t / Second / Third / Lowes t [n]
Use the + or – key to change the NB Temp. Limit of Highest / Second / Third / Lowest
value. Enter a decimal number between 0 and 127.
S YS Fan1 Highest Setting [100]
F81865 only support full speed in highest speed value.
S YS Fan1 Second / Third / Fourth / Lowest Setting [n]
Use the + or – key to change the NB Fan Second / Third / Fourth / Lowest speed. Enter
a decimal number between 12 and 100.
Monitored Values
The following system parameters and values are shown. The system parameters that are
monitored are:
The following system temperatures are monitored:
o CPU Temperature
o System Temperature
The following fan speeds are monitored:
o CPU Fan Speed
o SYS Fan1 Speed
The following core voltages are monitored:
o VCC3
o VCC_Core
o VIN1_1.5V
o VIN2_5V
o VIN3_12V
o VSB
