5.3.4 Hardware Health Configuration
The Hardware Health Configuration menu (BIOS Menu 7) shows the operating
temperature, fan speed and system voltages.
BIOS SETUP UTILITY
Advanced
Hardware Health Configuration

CPU FAN1 Mode Setting [Auto Fan by RPM]
CPU Temp. Limit of Highest [050]
CPU Temp. Limit of Second [040]
CPU Temp. Limit of Third [030]
CPU Temp. Limit of Lowest [020]
CPU FAN1 Highest Setting [100]
CPU FAN1 Second Setting [080]
CPU FAN1 Third Setting [070]
CPU FAN1 Fourth Setting [060]
CPU FAN1 Lowest Setting [050]
SYS FAN1 Mode Setting [Auto Fan by RPM]
SYS Temp. Limit of Highest [050]
SYS Temp. Limit of Second [040]
SYS Temp. Limit of Third [030]
SYS Temp. Limit of Lowest [020]
SYS FAN1 Highest Setting [100]
SYS FAN1 Second Setting [080]
SYS FAN1 Third Setting [070]
SYS FAN1 Fourth Setting [060]
SYS FAN1 Lowest Setting [050]

CPU Temperature :16ºC/60ºF
System Temperature :28ºC/82ºF
CPU Fan Speed :4918 RPM
SYS Fan1 Speed :N/A
VCC3 :3.312 V
VCC_Core :1.312 V
VIN_1.5V :1.560 V
VIN2_5V :5.016 V
VIN3_12V :11.968 V
VSB :3.392 V
VBAT :3.312 V
Fan configuration mode
setting
 Select Screen
↑ ↓ Select Item
+ - Change Option
F1 General Help
F10 Save and Exit
ESC Exit
v02.61 ©Copyright 1985-2006, American Megatrends, Inc.
BIOS Menu 7: Hardware Health Configuration
