Enabled DEFAULT
Allows BIOS to use 32-bit data transfers on supported
hard disk drives.
5.3.3 Super IO Configuration
Use the Super IO Configuration menu (BIOS Menu 6) to set or change the
configurations for the serial ports.
BIOS SETUP UTILITY
Advanced
Configure F81865F Super IO Chipset

Serial Port1 Address [3F8]
Serial Port1 IRQ [IRQ4]
Serial Port2 Address [2F8]
Serial Port2 IRQ [IRQ3]
Serial Port3 Address [3E8]
Serial Port3 IRQ [IRQ11]
Serial Port4 Address [2E8]
Serial Port4 IRQ [IRQ10]
Serial Port5 Address [338]
Serial Port5 IRQ [IRQ11]
Serial Port6 Address [328]
Serial Port6 IRQ [IRQ10]
Select RS232 or RS422/RS485 [RS232]
Parallel Port Address [378]
Parallel Port Mode [Normal]
Parallel Port IRQ [IRQ7]
Allows BIOS to select
Serial Port1 Base
Addresses
 Select Screen
↑ ↓ Select Item
+ - Change Option
F1 General Help
F10 Save and Exit
ESC Exit
v02.61 ©Copyright 1985-2006, American Megatrends, Inc.
BIOS Menu 6: Super IO Configuration
 Serial Port1 Address [3F8]
Use the Serial Port1 Address option to select the Serial Port 1 base address.


Disabled
No base address is assigned to Serial Port 1


3F8 DEFAULT
Serial Port 1 I/O port address is 3F8


2F8
Serial Port 1 I/O port address is 2F8
 Serial Port1 IRQ [IRQ4]
