KINO-G410 Mini-ITX Motherboard
Page 7
Serial Ports
Five RS-232 COM connectors
One RS-232/422/485 COM connector
USB 2.0/1.1 ports
Four internal via pin header
Four external USB ports
Parallel Port
One parallel port via 26-pin header
Serial ATA
Four independent SATA channels with 3.0 Gb/s data
transfer rates
Environmental and Power Specifications
Power Supply
ATX supported
Power Consumption
5 V @ 6.41 A
Vcore_12 V @ 2.52 A
3.3 V @ 0.27 A
(2.8 GHz Intel® Core™2 Duo E7400 with two 1 GB
1066 MHz DDR3 DIMMs)
Operating temperature
-10ºC ~ 60ºC, requires cooler and silicone heat sink paste
Humidity
5% ~ 95% (non-condensing)
Phys ical Specifications
Dimensions
170 mm x 170 mm
Weight (Gross/Net)
1100 g / 700 g
Table 1-1: Technical Specifications
