KINO-DQM871 Mini-ITX SBC
Page 51
LED Description LED Description
A on: linked
blinking: data is being sent/received
B off: 10 Mb/s
green: 100 Mb/s
orange: 1000 Mb/s
Table 3-33: Connector LEDs
The USB 2.0 connector can be connected to a USB device.
Pin Description
1 VBUS
2 D1-
3 D1+
4 GND
Table 3-34: External USB 2.0 Port Pinouts
3.3.3 Ethernet and USB 3.0 Connectors
CN Label: LAN1_USB1
CN Type:
RJ-45 and USB 3.0 combo connector
CN Location:
See Figure 3-31
CN Pinouts:
See Table 3-35 and Table 3-37
The LAN connector connects to a local network. It supports Intel® AMT 9.0.
PIN DESCRIPTION PIN DESCRIPTION
1 MDIA0+ 5 MDIA2-
2 MDIA0- 6 MDIA1-
3 MDIA1+ 7 MDIA3+
4 MDIA2+ 8 MDIA3-
Table 3-35: LAN1 Pinouts
