KINO-DQM871 Mini-ITX SBC
Page 42
Figure 3-23: SATA Power Connector Locations
Pin Description
1 +V12S
2 GND
3 GND
4 +V5S
Table 3-25: SATA Power Connector Pinouts
3.2.23 SMBus Connector
CN Label: SMB1
CN Type:
4-pin wafer
CN Location:
See
Figure 3-24
CN Pinouts:
See
Table 3-26
The SMBus (System Management Bus) connector provides low-speed system
management communications.
