KINO-DQM871 Mini-ITX SBC
Page 17
3.1.2 Peripheral Interface Connectors
The table below shows a list of the peripheral interface connectors on the KINO-DQM871.
Detailed descriptions of these connectors can be found below.
Connector Type Label
ATX power signal connector 3-pin header PS_ON1
Battery connector 2-pin wafer BAT1
Digital I/O connector 10-pin header DIO1
DisplayPort connector 20-pin box header DP1
EC debug port 20-pin header LPT_DB1
Fan connector (CPU) 4-pin wafer CPU_FAN1
Fan connector (system) 4-pin wafer SYS_FAN1
Front panel connector 14-pin header F_PANEL1
Keyboard/mouse connector 6-pin wafer KB_MS1
LAN active LED connector 4-pin header LAN_ACT_LED1
LVDS connector 30-pin crimp LVDS1
LVDS backlight connector 5-pin wafer INV1
PCIe Mini card slot Half-size PCIe Mini card slot MINI-PCIE1
PCIe Mini card slot Full-size PCIe Mini card slot M-SATA1
PCIe x16 slot PCIe x16 slot PCIEX16_1
Power button (on-board) Push button PWR_SW1
Power connector (12V) 4-pin connector PWR2
RS-232 serial ports 10-pin header COM2, COM3,
COM4, COM5
RS-422/485 serial port 4-pin wafer COM6
SATA 3Gb/s connectors SATA connector S_ATA3, S_ATA4
SATA 6Gb/s connectors SATA connector S_ATA1, S_ATA2
