KINO-DQM871 Mini-ITX SBC
Page 14
Item and Part Number Image
Infineon TPM module
(P/N: TPM-IN01-R11)
DisplayPort to 24-bit dual channel LVDS converter board
(For IEI IDP connector)
(P/N: DP-LVDS-R10)
DisplayPort to HDMI converter board
(For IEI IDP connector)
(P/N: DP-HDMI-R10)
DisplayPort to DVI-D converter board
(For IEI IDP connector)
(P/N: DP-DVI-R10)
DisplayPort to VGA converter board
(For IEI IDP connector)
(P/N: DP-VGA-R10)
DisplayPort to DisplayPort converter board for iEi IDP
connector
(P/N: DP-DP-R10)
Table 2-2: Optional Items
