KINO-DQM871 Mini-ITX SBC
Page 8
I/O Interface Connectors
Display Output Ports
(Triple Display
Supported)
1 x VGA (up to 1920 x 1200 @ 60 Hz)
2 x HDMI (up to 2500 x 1600 @ 60 Hz)
1 x 18/24-bit dual-channel LVDS (up to 1920 x 1200 @ 60 Hz)
1 x DisplayPort via on-board box header supports HDMI, LVDS, VGA,
DVI and DisplayPort (up to 3840 x 2160 @ 60 Hz)
Fan connector
One 4-pin wafer for CPU fan
One 4-pin wafer for system fan
Keyboard/Mouse
One internal 6-pin wafer connector
Serial Ports
Five RS-232 COM connectors (four by pin header, one on rear side)
One RS-422/485 COM connector (4-pin wafer)
USB Ports
Ten USB 2.0 ports (eight by 8-pin header, two on rear side )
Four USB 3.0 ports (two by pin header, two on rear side)
SMBus
One 4-pin wafer connector
TPM
One 20-pin header
Storage
SATA
2 x SATA 6Gb/s
2 x SATA 3Gb/s with RAID 0/1/5/10 support
Environmental and Power Specifications
Power Supply
12V only, AT/ATX support
Power Connector
1 x External 4-pin DIN DC jack
1 x Internal 4-pin (2x2) power connector
Power Consumption
12V@6.03A (2.4 GHz Intel® Core™ i7-4770EQ processor with two
4 GB 1333MHz DDR3 memory)
Operating Temperature
-20ºC ~ 60ºC (32ºF ~ 140ºF)
Storage Temperature
-30ºC ~ 70ºC
Operating Humidity
5% ~ 95% (non-condensing)
Physical Specifications
Dimensions
170 mm x 170 mm
