KINO-DQM871 Mini-ITX SBC
Page 7
1.7 Technical Specifications
KINO-DQM871 technical specifications are listed in Table 1-1.
Specification KINO-DQM871
Form Factor
Mini-ITX
On-board Processor
Intel® Core™ i7-4700EQ processor with Intel® AMT 9.0 support
(2.4 GHz, quad-core, 6 MB cache, 47 W TDP)
Intel® Core™ i5-4402E processor with Intel® AMT 9.0 support
(1.6 GHz, dual-core, 3 MB cache, 25 W TDP)
Intel® Core™ i3-4102E processor (1.6 GHz, dual-core, 3 MB cache,
25 W TDP)
Intel® Celeron® 2002E processor (1.5 GHz, dual-core, 2 MB cache,
25 W TDP
System Chipset
Intel® QM87
Memory
Two 204-pin 1600/1333/1066 MHz DDR3 SO-DIMM supported
(system max. 16.0 GB)
Graphics Engine
Supports DirectX 11.1, OpenGL 3.2, OpenCL 1.2, full MPEG2, VC1,
AVC decode
BIOS
UEFI BIOS
Ethernet Controllers
LAN1: Intel® I217 PHY (through PCIe x1) with Intel® AMT 9.0 support
LAN2: Intel® I211 PCIe Ethernet controller (through PCIe x1)
Audio
Realtek ALC662 HD Audio codec
Super I/O Controller
Fintek F81866
EC
ITE IT8519
Digital I/O
8-bit, 4-bit input/4-bit output
Watchdog Timer
Software programmable supports 1~255 sec. system reset
Expansion
1 x Full-size PCIe Mini slot (colay mSATA)
1 x Half-size PCIe Mini slot
1 x PCIe x16 slot
