KINO-DQM871 Mini-ITX SBC
Page 134
6.6 USB 3.0 Driver Installation
WARNING:
Do not run this driver’s installer (Setup.exe) from a USB storage device
(ie. external USB hard drive or USB thumb drive). For proper
installation, please copy driver files to a local hard drive folder and run
from there.
To install the USB 3.0 driver, please follow the steps below.
Step 1: Access the driver list. (See Section
6.2)
Step 2: Click “4-USB 3.0”.
Step 3: Locate the setup file and double click on it.
Step 4: The Welcome Screen in
Figure 6-20 appears.
Step 5: Click Next to continue.
Figure 6-20: USB 3.0 Driver Welcome Screen
