KINO-DQM871 Mini-ITX SBC
Page 121
6.1 Available Software Drivers
NOTE:
The content of the CD may vary throughout the life cycle of the product
and is subject to change without prior notice. Visit the IEI website or
contact technical support for the latest updates.
The following drivers can be installed on the system:
Chipset
Graphics
LAN
USB 3.0
Audio
Intel® AMT
Installation instructions are given below.
6.2 Starting the Driver Program
To access the driver installation programs, please do the following.
Step 1: Insert the CD that came with the system into a CD drive connected to the
system.
NOTE:
If the installation program doesn't start automatically:
Click "Start->Computer->CD Drive->autorun.exe"
Step 2: The driver main menu appears (Figure 6-1).
