KINO-DQM871 Mini-ITX SBC
Page 114
Disabled
The onboard High Definition Audio controller is disabled
Enabled DEFAULT
The onboard High Definition Audio controller
automatically detected and enabled
Power Saving Function [Disabled]
Use the Power Saving Function option to enable or disable power saving function.
Disabled DEFAULT
Power saving function is disabled
Enabled
Enable to reduce power consumption in system off state.
5.4.2.1 PCI Express Configuration
Use the PCI Express Configuration menu (BIOS Menu 25) to select the support type of
the PCI Express or PCIe Mini slots.
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
Chipset
PCI Express Configuration
M-SATA1 PCIE Port
PCIe Speed [Auto]
Detect Non-Compliance Device [Disabled]
MINI-PCIE1 PCIE Port
PCIe Speed [Auto]
Detect Non-Compliance Device [Disabled]
S
elect PCI Express port
speed.
----------------------
: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
BIOS Menu 25: PCI Express Configuration
PCIe Speed
Use PCIe Speed option to select the speed type of the PCI Express or PCIe Mini slots.
The following options are available:
Auto Default
Gen1
