KINO-DQM871 Mini-ITX SBC
Page 110
DVMT Total Gfx Mem [MAX]
Use the DVMT Total Gfx Mem option to select DVMT5.0 total graphic memory size used
by the internal graphic device. The following options are available:
128M
256M
MAX Default
Primary IGFX Boot Display [VBIOS Default]
Use the Primary IGFX Boot Display option to select the display device used by the
system when it boots. Configuration options are listed below.
VBIOS Default
DEFAULT
CRT
LVDS
Display port 1
HDMI 1
HDMI 2
Backlight Control [Inverted]
Use the Backlight Control option to select the backlight control mode.
Normal
The LVDS backlight is brighter at low voltage level.
Inverted DEFAULT
The LVDS backlight is brighter at high voltage level.
