KINO-DQM871 Mini-ITX SBC
Page 94
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
Advanced
Smart Fan Mode Configuration
Fan 1 Smart Fan Control [Auto Mode]
Auto mode fan start temperature 50
Auto mode fan off temperature 40
Auto mode fan start PWM 30
Auto mode fan slope PWM 1
Smart Fan Mode Select
---------------------
: Select Screen
↑ ↓: Select Item
Enter Select
+ - Change Opt.
F1 General Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
BIOS Menu 12: Smar Fan Mode Configuration
Fan 1 Smart Fan Control [Auto Mode]
Use the Fan 1 Smart Fan Control option to configure the CPU Smart Fan.
Manual Mode
The fan spins at the speed set in Manual by Duty
Cycle settings
Auto Mode DEFAULT
The fan adjusts its speed using Auto by
Duty-Cycle settings
Auto mode fan start/off temperature
Use the + or – key to change the Auto mode fan start/off temperature value. Enter a
decimal number between 1 and 100.
Auto mode fan start PWM
Use the + or – key to change the Auto mode fan start PWM value. Enter a decimal
number between 1 and 128.
Auto mode fan slope PWM
Use the + or – key to change the Auto mode fan slope PWM value. Enter a decimal
number between 1 and 64.
