KINO-DQM871 Mini-ITX SBC
Page 89
5.3.5 SATA Configuration
Use the SATA Configuration menu (BIOS Menu 7) to change and/or set the
configuration of the SATA devices installed in the system.
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
Advanced
SATA Controller(s) [Enabled]
SATA Mode Selection [IDE]
S_ATA1 Empty
S_ATA2 Empty
S_ATA3 Empty
S_ATA4(or mSATA) Empty
Enable or disable SATA
Device.
---------------------
: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
BIOS Menu 7: SATA Configuration
SATA Controller(s) [Enabled]
Use the SATA Controller(s) option to configure the SATA controller.
Enabled DEFAULT
Enable SATA controller.
Disabled
Disable SATA controller.
SATA Mode Selection [IDE]
Use the SATA Mode Selection option to configure SATA devices.
IDE DEFAULT
Configures SATA devices as normal IDE device.
AHCI
Configures SATA devices as AHCI device.
RAID
Configures SATA devices as RAID device.
