KINO-DQM871 Mini-ITX SBC
Page 88
Intel VT-x Technology: Indicates if Intel VT-x Technology is supported by the
CPU.
Intel SMX Technology: Indicates if Intel SMX Technology is supported by the
CPU.
EIST Technology: Indicates if the Enhanced Intel SpeedStep® Technology
(EIST) is supported by the CPU.
64-bit: Indicates if 64-bit is supported by the CPU.
L1 Data Cache: Lists the amount of data storage space on the L1 cache.
L1 Code Cache: Lists the amount of code storage space on the L1 cache.
L2 Cache: Lists the amount of storage space on the L2 cache.
L3 Cache: Lists the amount of storage space on the L3 cache.
Hyper-threading [Enabled]
Use the Hyper-Threading BIOS option to enable or disable the Intel Hyper-Threading
Technology.
Disabled
Disables the Intel Hyper-Threading Technology.
Enabled DEFAULT
Enables the Intel Hyper-Threading Technology.
Intel Virtualization Technology [Disabled]
Use the Intel Virtualization Technology option to enable or disable virtualization on the
system. When combined with third party software, Intel® Virtualization technology allows
several OSs to run on the same system at the same time.
Disabled DEFAULT
Disables Intel Virtualization Technology.
Enabled
Enables Intel Virtualization Technology.
Intel TXT(LT) Support [Disabled]
Use the Intel TXT(LT) Support BIOS option to enable or disable the Intel Trusted
Execution Technology.
Disabled DEFAULT
Disables the Intel Trusted Execution Technology.
Enabled
Enables the Intel Trusted Execution Technology.
