5.3.4 CPU Configuration
Use the CPU Configuration menu (BIOS Menu 6) to view detailed CPU specifications
and configure the CPU.
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
Advanced
CPU Configuration
Intel(R) Core(TM) i5-4402E CPU @ 1.60GHz
CPU Signature 306c3
Microcode Patch 8
Max CPU Speed 1600 MHz
Min CPU Speed 800 MHz
CPU Speed 2600 MHz
Processor Cores 2
Intel HT Technology Supported
Intel VT-x Technology Supported
Intel SMX Technology Supported
64-bit Supported
EIST Technology Supported
L1 Data Cache 32 kB x 2
L1 Code Cache 32 kB x 2
L2 Cache 256 kB x 2
L3 Cache 3072 kB
Hyper-threading [Enabled]
Intel Virtualization Technology [Disabled]
Intel TXT(LT) Support [Disabled]
Enabled for Windows XP
a
nd Linux (OS optimized
for Hyper-Threading
T
echnology) and Disabled
for other OS (OS not
optimized for
Hyper-Threading
Technology). When
D
isabled only one thread
per enabled core is
enabled.
----------------------
 : Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
BIOS Menu 6: CPU Configuration
The CPU Configuration menu (
BIOS Menu 6) lists the following CPU details:
 Processor Type: Lists the brand name of the CPU being used
 CPU Signature: Lists the CPU signature value.
 Microcode Patch: Lists the microcode patch being used.
 Max CPU Speed: Lists the maximum CPU processing speed.
 Min CPU Speed: Lists the minimum CPU processing speed.
 CPU Speed: Lists the CPU processing speed
 Processor Cores: Lists the number of the processor core
 Intel HT Technology: Indicates if Intel HT Technology is supported by the
CPU.
