KINO-9652 Mini-ITX SBC
Page 47
6 DATA 7 31 DATA 15
7 HDC_CS0# 32 HDC_CS1
8 N/C 33 N/C
9 GROUND 34 IOR#
10 N/C 35 IOW#
11 N/C 36 VCC_COM
12 N/C 37 IRQ15
13 VCC_COM 38 VCC_COM
14 N/C 39 CSEL
15 N/C 40 N/C
16 N/C 41 HDD_RESET
17 N/C 42 IORDY
18 SA2 43 SDREQ
19 SA1 44 SDACK#
20 SA0 45 HDD_ACTIVE#
21 DATA 0 46 66DET
22 DATA 1 47 DATA 8
23 DATA 2 48 DATA 9
24 N/C 49 DATA 10
25 VCC-IN CHECK2
50 GROUND
Table 4-6: CF Card Socket Pinouts
4.2.5 Fan Connectors
CN Label: SYS_FAN1 and SYS_FAN2
CN Type:
3-pin wafer connector (1x3)
CN Location: See
Figure 4-6
CN Pinouts: See
Table 4-7
The cooling fan connectors on the KINO-9652 provide a 12V, 500mA current to one CPU
cooling fan and one system cooling fan. There is a “sense” pin in the fan connector, which
