KINO-9652 Mini-ITX SBC
Page 44
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 +3.3V 11 +3.3V
2 +3.3V 12 -12V
3 GND 13 GND
4 +5V 14 PS-ON
5 GND 15 GND
6 +5V 16 GND
7 GND 17 GND
8 PW-OK 18 -5V
9 +VCC5SB 19 +5V
10 +12V 20 +5V
Table 4-5: ATX Power Connector Pinouts
4.2.4 CompactFlash® Socket (Optional)
CN Label: CF1 (solder side)
CN Type:
50-pin slot (2x25)
CN Location: See
Figure 4-5
CN Pinouts: See
Table 4-6
A CF Type I or Type II memory card is inserted to the optional CF socket on the solder
side of the KINO-9652.
