KINO-9652 Mini-ITX SBC
Page 35
1 Mini jumper pack
1 Quick Installation Guide
1 Utility CD
Table 3-1: Package List Contents
3.3.2 Optional Items
NOTE:
The items listed in this section are optional items that must be ordered
separately. Please contact your KINO-9652 vendor, distributor or
reseller for more information or, contact iEi directly by sending an email
to sales@iei.com.tw
.
The following optional items are available for the KINO-9652.
Quantity Item and Part Number Image
1 Dual port USB cable
(P/N: CB-USB02-RS)
1 RS-232/422/485 Cable
(P/N:32200-026500-RS)
