KINO-9652 Mini-ITX SBC
Page 34
3.3 Unpacking Checklist
NOTE:
If some of the components listed in the checklist below are missing,
please do not proceed with the installation. Contact the IEI reseller or
vendor you purchased the KINO-9652 from or contact an IEI sales
representative directly. To contact an IEI sales representative, please
send an email to sales@iei.com.tw
.
3.3.1 Package Contents
The KINO-9652 is shipped with the following components:
Quantity Item and Part Number Image
1 KINO-9652 SBC
1 IDE cable
(P/N: 32200-000052-RS)
2 SATA cables
(P/N: 32000-0628000-RS)
1 SATA power cable
(P/N: 32100-088600-RS)
1 I/O shielding
(P/N: 45002-4520C0-00-RS)
