2.9.3 Power Consumption
Table 2-3 shows the power consumption parameters for the KINO-9652 running with a
2.0GHz Intel® Core™2 Duo T7300 with a 800 MHz FSB and a 533 MHz 512MB DDR2
DIMM,
Voltage Current
+5V 2.5A
+12V 1.65A
5V Standby 0.01A
Table 2-3: Power Consumption
WARNING:
Do not disconnect the ATX connector when the KINO-9652 is powered
on and running. Please make sure to switch off the ATX power supply
prior to disconnect the ATX connector. Incorrect usage may cause
permanently damage to the KINO-9652.
NOTE:
If the KINO-9652 fails to boot due to improper usage, please clear the
CMOS by disconnecting the battery from the connector.
