KINO-9652 Mini-ITX SBC
Page 6
external)
Serial Ports
Three RS-232 (DB-9 connectors)
One RS-232/422/485 (14-pin header connector)
Keyboard/Mouse
Two PS/2 keyboard/mouse connectors
Infrared
One IrDA connector through the iTE IT8712F super I/O.
Supports:
Serial Infrared (SIR)
Amplitude Shift Keyed IR (ASKIR)
Extension
One PCI slot
One PCIe mini card slot
Digital I/O
8-bit digital I/O, 4 input / 4 output by super I/O
Audio
RealTek ALC883 with 7.1 channel HD audio interface
Ethernet
Intel® 82573L PCIe GbE controller
Intel® 82566MM PCIe GbE controller
TPM
Supports TPM v1.2 with 20-pin onboard pin-header
BIOS
AMI BIOS Label
Power
AT/ATX power
Power Consumption
5V@2.5A, +12V@1.65A and 5VSB@0.01A
(2.0GHz Intel® Core™2 Duo T7300 with a 800 MHz FSB
and a 533 MHz 512MB DDR2 DIMM)
Operating Temperature
0ºC (32°F) ~ 60°C (140°F)
Humidity
5%~95% non condensing
Physical Dimensions
170 mm x 170 mm (width x length)
Weight (GW/NW)
1000 g/362 g
Table 1-1: Technical Specifications
