KINO-9652 Mini-ITX SBC
Page 5
COM 3 and COM 4 port RI and voltage selection
LCD voltage selection
LVDS panel resolution selection
CF card setup (optional)
The location of these connectors on the motherboard can be seen in Figure 1-1. These
connectors are fully described in Chapter 3.
1.2.2 Technical Specifications
KINO-9652 technical specifications are listed in Table 1-1. Detailed descriptions of each
specification can be found in Chapter
2.
SPECIFICATION KINO-9652
Form Factor
Mini-ITX
CPUs Supported
Socket P Intel
®
Core™2 Duo with 533/667/800 MHz FSB
Chipsets
Northbridge: Intel® GME965
Southbridge: Intel® ICH8ME
Graphics Support
Intel® Graphics Media Accelerator (GMA) X3100
Display
CRT
HDTV:
Up to 1080i component output
Composite output for NTSC/PAL
LVDS: Dual channel 24-bit LVDS
Memory
Two 240-pin 2 GB (max.) 533/667 MHz dual-channel DDR2
SDRAM DIMM (maximum system memory of 4 GB)
Super I/O
iTE IT8712
Serial ATA (SATA)
Two SATA II connectors with 3.0 Gbps transfer rates
HDD Interface
One IDE channel supports two Ultra ATA 100/66/33 devices
USB Interfaces
Eight USB 2.0 devices supported (four internal and four
