KINO-9652 Mini-ITX SBC
Page 235
NOTE:
The Karaoke Mode is configured in the Sound Effect menu. To access Karaoke
configuration settings, click on the Sound Effect menu tab.
Sound Effect
Karaoke Mode
Equalizer
Speaker Configuration
Speaker Test
S/PDIF-In
S/PDIF-Out
Connector Sensing
HRTF Demo
Microphone Effect
General
NOTE:
Not all RealTek Sound Effect Managers have all the above listed options. The
Sound Effect Manager loaded onto the system may only have some of the
options listed above.
Below is a brief description of the available configuration options in the Sound Effects
Manager.
Sound Effect - Select a sound effect from the 23 listed options in the drop
down menu. Selected sound effect properties can be edited. Click E
DIT to edit
the sound effect.
Karaoke Mode - Karaoke Mode is accessed in the Sound Effect tab. The
Voice Cancellation disables the vocal part of the music being played. The
