KINO-9652 Mini-ITX SBC
Page 226
The following memory modules have been successfully tested on the KINO-9652.
Manufacturer Model No. Capacity Speed
CORSAIR VS51MB667D2 512 MB 667 MHz
CORSAIR VS1GB667D2 1 GB 667 MHz
CORSAIR VS2GB667D2 2 GB 667 MHz
Kingston KHX5400D2K2/2G 1 GB PC2-5400
Kingston KHX5400D2K2/1G 512 MB PC2-5400
Kingston KVR667D2N5/2G 2 G 667 MHz
A-DATA M2OEL5G3I4170C1C0z667(5)1GX16 1 GB 667 MHz
UNIGEN UG12T6400L8DU-5AM DDR2-533 1 GB 533 MHz
UNIGEN UG64T6400L8DU-5AL 512 MB 533 MHz
UNIGEN UG64T6400L8DU-6AL 512 MB 667 MHz
Transcend TS128MLQ64V8J DDR2-800 1 GB 800 MHz
Transcend TS64MLQ64V6J DDR2-667 512 MB 667 MHz
Transcend TS32MLQ64V6M DDR2-667 256 MB 667 MHz
Twinmos 8D22IB-ED 256 MB 533 MHz
Elixir M2U51264TU88A0F-37B DDR2-533 512 MB 533 MHz
Apacer UNB PC4300 CL4 512 MB 533 MHz
KINGSTEK PC2-4200 1RX16U5R 256 MB PC2-4200
KINGSTEK KSTD2PC2-4200 1RUX8U5R 256 MB PC2-4200
