Owner's manual

KINO-9652 Mini-ITX SBC
Page
X
I
X
List of Tables
Table 1-1: Technical Specifications ............................................................................6
Table 2-1: Supported Intel® Core™2 Duo (Merom) Processors ............................11
Table 2-2: Supported HDD Specifications................................................................20
Table 2-3: Power Consumption .................................................................................31
Table 3-1: Package List Contents..............................................................................35
Table 3-2: Optional Items ...........................................................................................36
Table 4-1: Peripheral Interface Connectors..............................................................40
Table 4-2: Rear Panel Connectors.............................................................................40
Table 4-3: Audio Connector Pinouts.........................................................................41
Table 4-4: Audio CD In Connector Pinouts ..............................................................42
Table 4-5: ATX Power Connector Pinouts ................................................................44
Table 4-6: CF Card Socket Pinouts ...........................................................................47
Table 4-7: Fan Connector Pinouts.............................................................................48
Table 4-8: Front Panel Connector Pinouts ...............................................................49
Table 4-9: GPIO Connector Pinouts ..........................................................................50
Table 4-10: IDE Connector Pinouts ...........................................................................52
Table 4-11: Infrared Connector Pinouts....................................................................53
Table 4-12: LCD Backlight Connector Pinouts ........................................................54
Table 4-13: LVDS LCD Connector Pinouts...............................................................56
Table 4-14: SATA Drive Connector Pinouts .............................................................57
Table 4-15: COM1 Pinouts..........................................................................................58
Table 4-16: TPM Connector Pinouts..........................................................................59
Table 4-17: TV Port Connector Pinouts ....................................................................60
Table 4-18: USB3 and USB4 Pinouts.........................................................................61
Table 4-19: VGA Connector Pinouts .........................................................................64
Table 4-20: LAN1 and LAN2 Pinouts.........................................................................65
Table 4-21: RJ-45 Ethernet Connector LEDs............................................................66
Table 4-22: PS/2 Connector Pinouts .........................................................................67
